석탄 연소 열 오일 보일러

Thermal Power: 30-1400 (10⁴Kcal/h)

Working pressure: 0.8-1.0 MPa

Outlet temperature: 320 °C

Available Fuel: Lignite, bituminous coal, anthracite, gangue
Gas fired thermal Oil Boiler is fueled by natural gas, heat is provided by natural gas burner, and heat transfer oil is the heat carrier. The circulating pump is used to force the thermal oil to circulate in the liquid phase and transfer the heat to one or more heat-using equipments Rated.



세부

태그

성능상의 이점



1. 낮은 작동 압력에서 더 높은 작동 온도를 얻을 수 있습니다.

2, 안정적인 가열과 정확한 온도 조정을 수행할 수 있습니다.

3, 완벽한 작동 제어 및 안전 감지 장치가 있습니다.

4, 다양한 작업 조건에서 최고의 열효율을 유지할 수 있습니다.

5, 액상 열 전달, <300℃의 열 운반체는 물의 포화 증기압보다 70-80배 작으며 열 전달 오일은 추운 지역에서 쉽게 얼지 않습니다.

6, 물이 부족한 증기 보일러 난방을 물을 매체로 대체할 수 있습니다.

7, 폐쇄 루프 가열, 열 이용 효율이 높습니다.



매개변수



모델

정격화력(Kw)

정격화력(10⁴Kcal/h)

설계 작동 온도(≤℃)

정격 사용 압력(Mpa)

열효율(≥%)

오일 용량(m³)

YQW-350 Y(Q)

350

30

320

1

95

0.3

YQW-460 Y(Q)

460

40

320

1

95

0.35

YQW-580 Y(Q)

580

50

320

1

95

0.4

YQW-700 Y(Q)

700

60

320

1

95

0.6

YQW-940 Y(Q)

940

80

320

1

95

0.78

YQW-1200 Y(Q)

1200

100

320

1

95

1.2

YQW-1400 Y(Q)

1400

120

320

1

95

1.35

YQW-1800 Y(Q)

1800

150

320

1

95

1.5

YQW-2100 Y(Q)

2100

180

320

1

95

2

YQW-2400 Y(Q)

2400

200

320

1

95

2.6

YQW-3000 Y(Q)

3000

250

320

1

95

3.2

YQW-3500 Y(Q)

3500

300

320

1

95

3.9

YQW-4000 Y(Q)

4000

350

320

1

95

4.5
